Information
|
CPU Socket |
Intel® Socket 1155 |
|
Kesesuaian Prosesor |
3rd/2nd Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
|
Northbridge Chipset |
Intel® H61(B3) |
|
Southbridge Chipset |
Intel® H61(B3) |
|
DIMM Sockets |
2 x DIMM |
|
Kesesuaian Memori |
DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1600/1333/1066 MHz Non-ECC, Un-buffered Memory |
|
Maks. Memori |
16GB (2 x 8GB) |
|
Expansion Slots |
1 x PCIe 3.0/2.0 x16 |
|
|
2 x PCIe 2.0 x1 |
|
Onboard VGA |
Integrated Graphics Processor : |
|
|
Dukungan output VGA : RGB port (Mendukung RGB dengan resolusi maks. 2048 x 1536 @ 75 Hz) |
|
|
Maximum shared memory of 1024 MB |
|
Audio |
Realtek® ALC887 8-Channel High Definition Audio CODEC |
|
LAN |
Realtek® 8111F, 1 x Gigabit LAN Controller(s) |
|
USB |
USB 2.0 |
|
BIOS |
64Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SMBIOS v2.7, ACPI v2.0a,SLP3.0, EUP-ready |
|
Internal I/O |
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) |
|
|
4 x SATA 3Gb/s connector(s) |
|
|
1 x CPU Fan connector(s) (4 -pin) |
|
|
1 x Chassis Fan connector(s) (4 -pin) |
|
|
1 x 24-pin EATX Power connector(s) |
|
|
1 x 4-pin ATX 12V Power connector(s) |
|
|
1 x Front panel connector(s) |
|
|
1 x Front panel audio connector(s) (AAFP) |
|
|
1 x Internal speaker connector(s) |
|
|
1 x Clear CMOS jumper(s) |
|
Form Factor |
uATX Form Factor (22.6 cm x 17.5 cm) |
|
Lain-lain |
ASUS Exclusive Features: |
|
|
AI Suite II |
|
|
Ai Charger |
|
|
Anti-Surge |
|
|
ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface |
|
|
Network iControl |
|
|
ASUS Quiet Thermal Solution: |
|
|
ASUS Fan Xpert |
|
|
ASUS EZ DIY: |
|
|
ASUS CrashFree BIOS 3 |
|
|
ASUS EZ Flash 2 |
|
|
ASUS MyLogo 2 |
|
|
100% All High-quality Conductive Polymer Capacitors |
