| Teknologi Cetak | On demand ink Jet |
| Maks. Resolusi | 5760 x 1440 dpi |
| Kecepatan Print | Max Black Draft Text - Memo (A4) |
| Approx. 33 ppm / 15 ppm (Black/Colour) | |
| ISO 24734, A4 | |
| Approx. 9.2 ipm / 4.5 ipm (Black/Colour) | |
| Max Photo Draft - 10x15cm/4x6"*2 | |
| Approx. 27 sec per photo (W/Border) | |
| Photo Default - 10x15cm/4x6"*2 | |
| Approx. 69 sec per photo (W/Border) | |
| Kecepatan Meng-Copy | Max Draft Text - Memo (A4) |
| Approx. 5.0sec/10sec (Black/Colour) | |
| Maximum Copies from Standalone | |
| 20 copies | |
| Maximum Copy Size | |
| A4, Letter | |
| Scanning | Scanner Type |
| Flatbed colour image scanner | |
| Sensor Type | |
| CIS | |
| Optical Resolution | |
| 600 x 1200 dpi | |
| Maximum Scan Area | |
| 216 x 297mm (8.5 x 11.7”) | |
| Scanner Bit Depth | |
| Colour | |
| 48-bit input, 24-bit output | |
| Grayscale | |
| 16-bit input, 8-bit output | |
| Black & White | |
| 16-bit input, 1-bit output | |
| Scan Speed (Flatbed) | |
| Monochrome 300 dpi | |
| 11 sec | |
| Colour 300 dpi | |
| 33 sec | |
| Paper Handling | Paper Feed Method |
| Friction feed | |
| Paper Hold Capacity | |
| Input Capacity | |
| 100 sheets, A4 Plain paper (75 gsm) | |
| 20 sheets, Premium Glossy Photo Paper | |
| Output Capacity | |
| 30 sheets, A4 Plain Paper | |
| 20 sheets, Premium Glossy Photo Paper | |
| Paper Size | |
| A4, A5, A6, B5, 10x15cm (4x6"), 13x18cm (5x7"), 9x13cm (3.5x5"), Letter, Legal, Half Letter (5.5x8.5"), 13x20cm (5x8"), 20x25cm (8x10"), 16:9 wide size, 100x148mm, Envelopes: #10 (4.125x9.5"), DL (110x220mm), C6 (114x162mm) | |
| Maximum Paper Size | |
| 215.9x1117.6mm (8.5 x 44") | |
| Print Margin | |
| 3mm top, left, right, bottom | |
| USB | Hi-Speed USB 2.0 |
| Sistem Operasi | Windows XP / XP Profesional x 64 Edition / Vista / 7 / 8 / 8.1 Max OS X 10.6.8 / 10.7.x / 10.8.x / 10.9.x |
| Spesifikasi Daya | Rated Voltage |
| AC 220-240V | |
| Rated Frequency | |
| 50 ~ 60Hz | |
| Power Consumption | |
| Operating 13W | |
| Standby 3.8W | |
| Sleep 0.8W | |
| Power Off 0.3W | |
| Tingkat Kebisingan | PC Printing / Premium Glossy Photo Paper Best Photo |
| 5.2 B(A), 38 dB(A) PC | |
| Printing / Plain Paper Default | |
| 5.9 B(A), 46 dB(A) | |
| Dimensi | 482 mm x 300 mm x 145 mm |
| Berat | 4.4 Kg |
